| Technical Details | |
|---|---|
| d1 | #10 |
| d2 | 6 |
| Drill Ø | 3.8 |
| Finish | Blu |
| Helix Angle | R45 |
| l1 | 70 |
| l2 | 8 |
| Lead | Form C / 3 x P |
| Material | HSSE V3 |
| Max Cut Depth | 3xD |
| sq | 4.9 |
| Thread Form | UNC |
| TPI | 24 |
| Type | Spiral Flute |
TAP T261 UNC 10-24 2B SPIRAL R45 VA-DH DIN2184-1 C HSSE BLU
$60.37inc
GST
Spiral Flute Taps – R45 VADH
- General purpose use, materials up to approx. 1000 N/mm2
- Blind holes
- Suitable for machine operations
- Depths up to approx. 2.5 x d1
View all: High Performance Taps - Spiral Flute
We don't have any datasheets for this product.
We don't have any media for this product.
This product is handy for all trades.
